18-10042 CMW
Part #: 295-18-10042
Request 3D Model
This water connector head is designed to mount to 100 Series Straight Holders
The head is made from Brass
- The overal length is 1.47 IN
- The width of the flats is 1.5 IN
- The head mounts to the holder barrel via 3/4 - 16 threads
- The head is designed for use with 5RW tapers, 7RW tapers or threaded end
- The part is designed for use with 100 Series Holders
- The part is nickel plated for wear resistance.
- The angle between the water connections is 60 degrees
Specifications
| Material | Brass |
|---|---|
| For use Barrel Electrode End | 3/4 - 16 |
| Holder Series Type | 100 Series Holder |
| Overall Length [A] | 1.47000 |
| Width between Flats [N] | 1.50000 |
| Unit of Measure | IN |
| Nickel Plating | Yes |
| Angle Between Hose Barbs | 60 |
